  • frames and nav (ui/w/shell/navmulti) README

  • ui/w/shell/navmulti is one of the fundamental components for the framework.

  • Todo

    • delete all keys on frame_register (reset state to unknown)
    • remove the getView because it is view agnostic
    • consolidate the resolveAndLoadPackageFromFullName with kernel/path stuff
    • generic frame communication, i.e. ['framenavigate', '../info/1', 'UniversalframeId']
    * we current only support communicate to '..' which is still very good. We already have parent via '..' but we need to do generic.

    * we need to be able to notify other frames in the system.

    Functions

    • Incrementally maps a URI to functional pieces with are configured via the URI. These pieces can be defined on the fly (via calling frame_register). Each piece is called a frame.

    * Most common use case is for defining UI hierarchy and embedding apps so that each app can be inserted/removed from the hierarchy independent of the others.

    * Also used for Machine Experience builder content generation
    • for each frame, the local url ->

    matches (serialized version from the url)

    params (environment info such as fullPath, path, currentUrlMatchedAgainst, etc.)

    • validation is not done by this. Instead whether the context is running in circus or UI calcValidationState is called to accomplish this. See the notes for apps/pulse/viewer/collection/slide.js
    • This will only care about
    * How frames are created/destroyed/updated as state changes

    * nested and heierachial definition of URI schemes to frame components (calcNav, etc)

    * Communication between these frames (frame_notify, etc.)

    Pieces

    differentiate between '.' and '.*/'

    * info/itemId/children will not work without this

    • improve the way current frame state is communicated and get rid of modnav concept

    * the old system uses framegetnavparams / framegetparams / framegetstate

    * the return modtask.params

    * framegetkey also sets modtask._matches ({"list"","tagselection1,"offset":0,"limit":50})

    * instead we will just use frame_getkey, 'framestate' and will have

    fullPath: '/dashboard/list/542147/list'

    path: '/tagselection/./offset/./limit/.',

    params: '',

    currentUrlMatchedAgainst: '',

    matches: { "list"","tagselection1,"offset":0,"limit":50 },

    kvs: {}, // same as matches

    previous: {},

    current: {},

    next: {},

    all: [],

    currentIndex: 0

    * choose names that are easier to use

    * instead of referencing the modtask.modnav, make the thing available as keys

    * this is important for the editor mode because we may recreate or renew the module but not neccessarily recreate the frame.

    * have something for 'iteration' so that next/last implementations are super easy (check the info/adjust/view)

    • Serialize/Deseriazlie a URI to internal states
    • Implements the frame_navigate that does these things (pieces may need to be decoupled, etc.)

    * Update the state

    * Update the URL

    * notify state change to the correct handler

    • implement get/set key mechanism within a frame context to simplify sharing of stuff between frame children.

    ChangeLog

    different between '.' and '.*/' to allow handling children for 'info//markdown'. Otherwise the will be 123/markdown

    • reuse frame on frame_register if already exists

    * This is needed to make sure that interactive design is possible. Otherwise when people edit the frame it will get reset and all will be reuined.

    • improved get/set key to accept collection

    * this will make the code simpler and more readable

    • add ability to notify parent frame and set outcome via frame_notify. This makes notifications easier and bubbling up notifications a lot faster.

    * With this, we can do a 1 liner pass thru to the upper level

    ['frame_notify', 'outcome', '..']

    * At the lower level we can do

    ['frame_notify', { succeess: true, ... }]

    • added feature to specify target frame for frame_xxx ops.
    * This will enable cross frame data exchange (e.g. apps/pulse/viewer/info/adjust).
    • Using isolateNav to have the ability to enable/disable url mode at each level.
    * Sometimes (for example for SxS scenarios) we want to decouple the view changes from the url. Currently, at the app top level we have

    var modnav = modtask.ldmod('ui/w/shell/navmulti/multi');

    modnav.setup(modtask);

    modnav.enableUrlMode();

    which is global. The issues are when someone does 'frame_register', they get put into a hierarchy and from that point on all the url changes will run through them. Need to be able to isolate a frame when we do frame register.

    • Implemented dotdot navigation up ['frame_navigate', '../info/1']
    • Fixed the case where a path match without a slash would not get captured
    • Added logging capabilities
    • Moved stateToPath and uriMatches functionality from apps/pulse into the framework. the stateToPath is now accomplished by allowing the passing of a JSON object to frame_navigate.
    • uriMatches handle uridecode/encode
