izy-devops

Perform devops actions such as connecting the Izy Platform to Amazon Web Services (AWS) should be easy. In this article we discuss common problems and issues that may arise.

Install

To install the tools for global access to izy.devops command, use:

curl -o- https://raw.githubusercontent.com/izyware/devops/master/sh/install.sh | bash

Working with AWS CLI Profiles

Most users have their machines setup so that they have have a an ~/.aws/config file with different profiles:

[default]

region = us-east-1

role_arn = arn:aws:iam::XXXXX:role/engineer

source_profile = default

[profile john]

role_arn = arn:aws:iam::YYYYY:role/marketing

source_profile = default

[profile james]

role_arn = arn:aws:iam::ZZZZ:role/marketing

source_profile = default

This will allow you to pass --profile john to the CLI.

However, AWS node SDK does not support the profile option. You can always verify the "current user" by:

izyaws.sh userId sts get-caller-identity

Or, from the scripting environment:

const sts = new AWS.STS();

sts.getCallerIdentity((err, data) => {

console.log(err, data);

});

To work around this problem, you can use assume role:

izyaws.sh sts assume-role --role-arn "arn:aws:iam::xxxx" --role-session-name yourname --duration-seconds 3600

Remember that new IAM users by default may not have any permissions or be part of any groups. You can use the following as a starting point:

// full access to AWS services and resources.

{

"Version": "2012-10-17",

"Statement": [

{

"Effect": "Allow",

"Action": "*",

"Resource": "*"

}

]

}

You can then set

export AWSACCESSKEY_ID=

export AWSSECRETACCESS_KEY=

export AWSSESSIONTOKEN=

After you are done, be sure to unset the variables by

unset AWSACCESSKEYID AWSSECRETACCESSKEY AWSSESSIONTOKEN

If you need to generate a One Time Password from the cli use

izy.devops "otp?generate" queryObject.secretStrBase32 your_secret

izy.devops "otp?generate" queryObject.secretPath ~/.aws/otpsecret

izy.devops "otp?generate" queryObject.secretPath ~/googleAccount1/otpsecret

To create an aws session automatically using the otp feature do

izy.aws "sts?newSession"

Debugging AWS Node SDK Network Traffic

You can use the following snippet inside aws-sdk/lib/http/node.js.

console.log('HTTP_REQUEST', JSON.stringify(httpRequest, null, 2));

var stream = http.request(options, function (httpResp) {

console.log('OK-------------------------');

var str = '';

var response = httpResp;

response.on('data', function (chunk) {

str += chunk;

});

response.on('end', function () {

console.log({

success: true,

responseText: str,

status: response.statusCode,

headers: response.headers

});

});

return ;

Working with SSH and RSYNC to access containers

You can access the ssh scripts by the ssh prefix:

izy.devops "ssh?shell" MACHINE_ID

izy.devops "ssh?runx" . "xeyes"

izy.devops "ssh?socksproxy" MACHINE_ID

[container] izy.devops "ssh?publishssh" $HOME/vpn 8022

[vpn] izy.devops "ssh?localforward" .

[local] izy.devops "ssh?socksproxy" . remote

izy.devops "rsync?download" . "~/Downloads/" ~/izyware/izy-idman-tools/id/x/Desktop/Downloads/

izy.devops "rsync?upload" . "~/Downloads/" ~/izyware/izy-idman-tools/id/x/Desktop/Downloads/

izy.devops "rsync?nodesync" ~/plat/p/servers/machine "~/codepath" appname

If your containers dont have key-pair setup, create the key-pair and push to the remote server:

cd CONTAINER_DIR;

ssh-keygen -f ./id_rsa

chmod 400 id_rsa*

mv id_rsa* config

ssh-copy-id -i ./config/id_rsa.pub user@server

Then test it with

izy.devops "ssh?shell .

pem file permissions

You may get the following error when trying to SSH into the EC2 instance:

@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@

@ WARNING: UNPROTECTED PRIVATE KEY FILE! @

@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@

Permissions 0644 for 'private.pem' are too open.

To fix this chmod to

chmod 400 private.pem

Setting up VPN for your organization

Server Setup

For the VPN server, we recomment using one of the standard AMIs that is maintainated and kept secure and up to date such as OpenVPN Access Server Community Image (AWS marketplaces OpenVPN Access Server-2-8-5). A t2.small with 8GB storage should be sufficient for all practical purposes. Pick the region that is geographically closest to your users.

One you launch the EC2, you should ssh into the machine. You will be greeted by the automatic setup script. Choose the following configuration options:

• default cypher algorithms (secp384r1)
• port number for the Admin Web UI: 943
• TCP port number for the OpenVPN Daemon: 443
• Do you wish to login to the Admin UI as "openvpn"? Yes
• Should client traffic be routed by default through the VPN? Yes default [no]
• Should client DNS traffic be routed by default through the VPN? Yes default [no]
• Should private subnets be accessible to clients by default? yes
• You will also create a (username, password) pair for clients: if you need to update the password use:

sudo passwd username

If you need to make futher changes to the server such as setting up SSO, etc. it can be configured by accessing its Admin Web UI using your Web browser.

Client Setup

Access the Client UI at https://SERVER_IP:943/ using the credential created above and download the client.ovpn file. Also place the (username, password) pair in the auth-user-pass.txt.

You can copy the files to your destination client machine by doing

izy.devops "rsync?upload" . "PATH/servers/vpn-serverid/" clientmachinepath/servers/vpn-serverid

Use the following command:

izy.devops "openvpn?connect" . SUDO_PASSWORD

Note that the client will need sudo to get on the vpn.

Using the openVPN Client in the IzyShell docker container

The openvpn client uses the dev/net/tun device. With docker > 1.2 you should use use:

--cap-add=NET_ADMIN

--device /dev/net/tun

If you are using an earlier version, you'll have to run it in privileged mode.

To make sure that the DNS will always work, you should make sure that your DNS server is routed through the eth0 interface. For this reason always use the utilities provided in the ~/vpn folder:

~/vpn_connect.sh connectionfile.ovpn

OR

~/vpnconnectsocks.sh connectionfile.ovpn

~/vpn_disconnect.sh

The VPN server will be sending commands to setup the tun interface devices. You should check the client output for:

/sbin/ifconfig utun...

Then on the container check the routing config and the utun devices:

ifconfig

netstat -rn

and make sure that the tun interface is recieving traffic.

Then try connecting to a known IP address without using the DNS:

nc -v myserviceip myserviceport

The test the DNS,

cat /etc/resolv.conf

host izyware.com

Offer a SOCKS server via the VPN interface

To get the IP address for the VPN network interface, do

VPNSERVICEIP=ifconfig | grep 172 | awk -F'[: ]+' '{ print $3 }'

Then use SSH

ssh -v -o StrictHostKeyChecking=no -ND "*:19009" test@$VPNSERVICEIP

Tunneling the VPN via SOCKS

OpenVPN support tunneling the openVPN Client via SOCKS. OpenVPN expects a a SOCKS5 server. Notice that openSSH implementation of SOCKS5 does not support UDP and trying to connect to openSSH will result in:

debug1: Connection to port LOCALPORT forwarding to socks port 0 requested.

debug2: fd 6 setting TCP_NODELAY

debug2: fd 6 setting O_NONBLOCK

debug3: fd 6 is O_NONBLOCK

debug1: channel 2: new [dynamic-tcpip]

debug2: channel 2: pre_dynamic: have 0

debug2: channel 2: pre_dynamic: have 3

debug2: channel 2: decode socks5

debug2: channel 2: socks5 auth done

debug2: channel 2: pre_dynamic: need more

debug2: channel 2: pre_dynamic: have 0

debug2: channel 2: pre_dynamic: have 10

debug2: channel 2: decode socks5

debug2: channel 2: socks5 post auth

debug2: channel 2: only socks5 connect supported

However, successful connections would have resulted in ()

debug2: channel 8: dynamic request: socks5 host IP port 443 command 1

The reason is openSSH does not support "UDP ASSOCIATE" (only "SSHSOCKS5CONNECT"). See rfc1928 for more details.

To address this issue, either use protoco TCP (you would need to do the same for using http proxy because proxying is only supported for the TCP protocol). i.e. to have TCP enabled for your openVPN server:

/etc/openvpn/server.conf

/var/log/syslog

service openvpn status

service openvpn restart

As an alternative, you may use vendors that are SOCKS5 compliant. We recommend dante:

git clone https://github.com/wernight/docker-dante

sudo docker build --rm -t izyidman_dante .

sudo docker run -d -p 1080:1080 izyidman_dante

AWS Quirks

Use the following tools and processes to workaround the issues from aws.

Codebuild

You can check the latest build status and logs by:

izy.aws "codebuild?check" queryObject.izyUser 86 queryObject.showLogs true queryObject.projectName myProject

Exploring codebuild setup and viewing a build projects details

npm run codebuild.projectDetails queryObject.izyUser 86 queryObject.projectName myProject

To debug your code build scripts (buildspec.*) use the provided docker Image:

docker build -f codebuild/Dockerfile -t izy-aws-codebuild:7.0 .;

You can then shell into the environment and run your commands:

docker run -e BUILDDIR=pwd --env-file ~/dockerenv-file.list -v /var/run/docker.sock:/var/run/docker.sock -v pwd:/sourcedirectory -it --entrypoint sh izy-aws-codebuild:7.0 -c bash;

docker_shell>rsync -av /sourcedirectory/ ~/src;

dockershell>killanddeletedata.sh imagekeyword (i.e. sql)

Notice that if you dont have a env file or AWS credentials are not available as environment variables you share your .aws folder:

-v echo ~/.aws:/root/.aws

If your application generates or uses docker containers as part of its CICD, you will need to use privilaged mode inside codebuild. Notice that the filesystem/volume mapping and network interfaces addresses can get confusing in this case. The most common issue reported on MacOS platforms vs Linux (Codebuild) is that the docker-compose volume mapping (using the volumes block) on Mac will only work if full path to host operating system is provided. Therefore, it is recommended to use the BUILD_DIR variable. The other common issue reported for MacOS is that passing environment variables with newline from MacOS to the container environment will endup converting the newlines to "\n" string which could be a problem. If your code relies on environment variables for file generation, you should take this into account and convert "\n" to new line (for example by using awk or sed).

Docker Tools

You may use the dockertools/serviceprobe docker image to troubleshoot these issues. Refer to the Dockerfile for more information and examples about how to use the tool. Notice that if you are using dockercompose you can specifiy the following in the environment section:

ENV CONTAINER_CONTEXT: Service Probe

ENV SLEEP_SECONDS: 5

ENV CMDTORUN: /usr/bin/nc -vz localhost 3306

You can launch dockerized browser instances using the following options:

use docker-firefox container image:

izy.devops "docker?firefox" .

The following are the recommended customization for maximum security and interoperability:

• Some users have reported issues for pages accessing the clipboard. Make sure to do about:config > clipboard and set all the flags to true.
• Some online services are sensitive to the user agent string and even when connecting from the same IP, when the user string is different they will detect it and may introduce issues. To override do about:config > general.useragent.override
• Use a socks server about:settings > socks

* Also set network.proxy.socksremotedns, otherwise some DNS lookups may fail

• Timezone is still broken. Notice that setting privacy.resistFingerprinting will not address the timezone issue and it will break the useragent customization.

use docker-chrome container image:

izy.devops "docker?chrome" .

If you need to shell into the container to test networking, etc.

docker run -it --entrypoint sh --name=firefox -p 5800:5800 -v folder_mapping jlesage/firefox -c sh

Route53

• Redirect apex domain to www using Route 53: You should create an S3 bucket, Properties > Static website hosting and setup Redirect requests. Once thats setup, you can add a record for A - IPv4 address. Select Yes for Alias, and enter the S3 bucket you created earlier.

Terraform

We recommend using the Terraform docker image. We provide template apps in the apps folder. As an example, to quickly setup and deploy a static website for a domain follow these steps:

Deep clone the app directory:

rsync -rv apps/static-website/ myfolder

cd myfolder;

Update the variables (domain, aws credentials, etc.) inside the

vi terraform_config.sh

Make sure that you dont use the naked (apex) domain name and use a prefix (www, etc.). DNS protocol does not support CNAME records or 301 redirects for the apex record. See the section regarding AWS Quirks below to learn how to redirect the apex to your subdomain (domain -> www.domain).

Shell into the image:

docker run -v pwd:/izyhostdir -it --entrypoint sh hashicorp/terraform:latest

Once inside the image, do:

clear; cd /izyhostdir; source ./terraform_config.sh; terraform apply -auto-approve;

The output should print the list of environment variables that will be used below:

export AWSCLOUDFRONTDISTRIBUTIONDOMAINNAME=GRABFROMTERRAFORM_OUTPUT;

export AWSCLOUDFRONTDISTRIBUTIONID=GRABFROMTERRAFORMOUTPUT;

export AWSS3BUCKETID=GRABFROMTERRAFORMOUTPUT;

You can push your files to the s3 bucket:

izyaws.sh s3 cp /izyhostdir/src s3://$AWSS3BUCKET_ID --recursive

Make sure to invalidate the cloudfront distribution after the push

izyaws.sh cloudfront create-invalidation --distribution-id $AWSCLOUDFRONTDISTRIBUTION_ID --paths "/*"

Terraform Quirks

• awscloudfrontdistribution

* when this is being created for the firsttime, you might get a "Missing required argument" error, followed by The argument "origin.0.domain_name" is required, but no definition was found.. rerunning the plan will address this.

* viewer_certificate block for cloudfront will only accept certificates that are in us-east-1, regardless of your region.

Docker

When running out of space, do

deleteall.sh

If you have a stateful container (i.e. mysql), you should stop and delete its state by

killanddeletedata.sh grepStr (mysql)

To build runtimes

docker build -f dockertools/nodejs/Dockerfile -t izy-nodejs:16.0 .;

docker run -it --entrypoint sh izy-nodejs:16.0 -c bash;

Links

github

ChangeLog

V7.4

• 74000003: fix install script and use sudo npm link

* customers reported EACCES: permission denied on Ubuntu

• 74000002: remove git dependency from install script
• 74000001: implement openvpn?connect tool

V7.3

• 73000028: implement SSHOPTIONSCLI for controlling StrictHostKeyChecking

* useful for headless and automation environments

• 73000027: add explicit ServerAliveInterval for client
• 73000026: implement portforwarding and remote ssh access and add support for non standard ssh service port 22
• 73000025: update help message
• 73000024: implement device switch firefox web extension

* access from about:debugging > This Firefox > Load Temporary Add on .. > /browserdir

• 73000023: add containerized chrome to dockertools
• 73000022: implement help command. update README
• 73000021: implement install script
• 73000020: add containerized firefox to dockertools
• 73000019: add standard containerized izy-proxy runtimes to dockertools
• 73000018: implement socks proxy via ssh

V7.1

• 7100005: implement nodesync functionality
• 7100004: add the ssh and rsync scripts
• 7100003: rename from izy-aws to izy-devops
• 7100002: clean environment variables for sts session before calling aws cli

* if set incorrectly aws cli will fail

• 7100001: implement automatic sts session creation using the OTP feature

V7.0

• 7000002: codebuild scripts bug fix and improvements
• 7000001: add support for OTP generation

V6.9

• 6900005: add codebuild docker image
• 6900004: add dockertools scripts
• 6900003: add dockertools/serviceprobe
• 6900002: add apps/static-website sample app with terraform
• 6900001: Codebuild - implement projectDetails

* useful for exploring codebuild setup and viewing a build projects details in AWS CodeBuild

* utilize callpretty for better output

* add verbose logging

V6.8

• 6800002: Codebuild migration
• 6800001: initial migration

dante: https://github.com/wernight/docker-dante

docker-firefox: https://github.com/jlesage/docker-firefox

docker-chrome: https://github.com/kasmtech/workspaces-images

github: https://github.com/izyware/devops
